Shockwave Lights: Coordinates for MAIW models

Discuss anything here...nothing political or controversial please.
flyboy
Captain
Captain
Posts: 387
Joined: 13 Aug 2006, 11:41
Version: P3D
Location: North Alabama

Post by flyboy »

CDAI KC-10 Unverified

light.0 = 3, -36.8, -82.56, -1.98, fx_shockwave_navred
light.1 = 3, -36.8, 82.56, -1.98, fx_shockwave_navgre
light.2 = 2, -36.8, -82.56, -1.98, fx_shockwave_strobe_l
light.3 = 2, -47.8, 82.56, -1.98, fx_shockwave_strobe_l
light.4 = 2, -47.8, -82.56, -1.98, fx_shockwave_strobe_l
light.5 = 2, -36.8, 82.56, -1.98, fx_shockwave_strobe_l
light.6 = 1, 3.72, 0.00, 7.55, fx_shockwave_beaconh
light.7 = 1, 3.72, 0.00, -12.05, fx_shockwave_beaconb
light.8 = 2, -0.5 , -27.5 , -10.8 , fx_nicksmokeAI_747
light.9 = 2, -88.5 , 0 , 10.2 , fx_nicksmokeAI_747
light.10 = 2, -0.5 , 27.5 , -10.8 , fx_nicksmokeAI_747
light.11 = 5, 24.5, -9.5, -6, fx_shockwave_landing_light_narrow
light.12 = 5, 24.5, 9.5, -6, fx_shockwave_landing_light_narrow
light.13 = 5, 70, -8.5, -5, fx_shockwave_landing_light_narrow
light.14 = 5, 70, 8.5, -5, fx_shockwave_landing_light_narrow
light.15 = 6, 62.7, -0.8, -13, fx_shockwave_landing_light_narrow
Lead, Follow, or get the Hell out of the way!

User avatar
MIKE JG
MAIW Developer
MAIW Developer
Posts: 10742
Joined: 12 Aug 2006, 02:25
Version: FS9

Post by MIKE JG »

HTAI F-16C



[lights]
//Types: 1=beacon, 2=strobe, 3=navigation, 4=cockpit, 5=landing 6=taxi
light.0 = 2, -19.70, 0.00, 11.45, fx_shockwave_strobe_l ,
light.1 = 3, 10.70, -2.30, -1.50, fx_iris_navred ,
light.2 = 3, 10.70, 2.30, -1.50, fx_iris_navgreen ,
light.3 = 3, -18.60, 0.00, 3.37, fx_f16_navwhih ,
light.4 = 3, -7.00, -15.00, 0.60, fx_iris_navred ,
light.5 = 3, -7.00, 15.00, 0.60, fx_iris_navgreen ,
light.6 = 3, -12.70, -3.20, 0.87, fx_f16_navwhih ,
light.7 = 3, -12.70, 3.20, 0.87, fx_f16_navwhih ,
light.8 = 3, 5.00, -0.00, 2.85, fx_f16_navwhih ,
light.9 = 3, 5.00, -0.00, -2.85, fx_f16_navwhih ,
light.10 = 6, 11.00, 0.75, -3.75, fx_shockwave_landing_light_narrow ,
light.11 = 2, -18.40, 0.00, -0.15, fx_f16_ab ,

Use this entry for the F-16C Drag Chute model: (Thanks to Steve "Firebird" Hadlow for keeping me honest) The slight difference is in bold type.

[lights]
//Types: 1=beacon, 2=strobe, 3=navigation, 4=cockpit, 5=landing 6=taxi
light.0 = 2, -19.70, 0.00, 11.45, fx_shockwave_strobe_l ,
light.1 = 3, 10.70, -2.30, -1.50, fx_iris_navred ,
light.2 = 3, 10.70, 2.30, -1.50, fx_iris_navgreen ,
light.3 = 3, -20.40, 0.00, 4.36, fx_f16_navwhih ,
light.4 = 3, -7.00, -15.00, 0.60, fx_iris_navred ,
light.5 = 3, -7.00, 15.00, 0.60, fx_iris_navgreen ,
light.6 = 3, -12.70, -3.20, 0.87, fx_f16_navwhih ,
light.7 = 3, -12.70, 3.20, 0.87, fx_f16_navwhih ,
light.8 = 3, 5.00, -0.00, 2.85, fx_f16_navwhih ,
light.9 = 3, 5.00, -0.00, -2.85, fx_f16_navwhih ,
light.10 = 6, 11.00, 0.75, -3.75, fx_shockwave_landing_light_narrow ,
light.11 = 2, -18.40, 0.00, -0.15, fx_f16_ab ,
Last edited by MIKE JG on 17 Nov 2008, 21:51, edited 1 time in total.
-Mike G.

User avatar
MIKE JG
MAIW Developer
MAIW Developer
Posts: 10742
Joined: 12 Aug 2006, 02:25
Version: FS9

Post by MIKE JG »

HTAI F-16D


[lights]
//Types: 1=beacon, 2=strobe, 3=navigation, 4=cockpit, 5=landing 6=taxi
light.0 = 2, -19.70, 0.00, 11.45, fx_shockwave_strobe_l ,
light.1 = 3, 10.70, -2.30, -1.50, fx_iris_navred ,
light.2 = 3, 10.70, 2.30, -1.50, fx_iris_navgreen ,
light.3 = 3, -18.60, 0.00, 3.37, fx_f16_navwhih ,
light.4 = 3, -7.00, -15.00, 0.60, fx_iris_navred ,
light.5 = 3, -7.00, 15.00, 0.60, fx_iris_navgreen ,
light.6 = 3, -12.70, -3.20, 0.87, fx_f16_navwhih ,
light.7 = 3, -12.70, 3.20, 0.87, fx_f16_navwhih ,
light.8 = 3, 2.30, -0.00, 2.70, fx_f16_navwhih ,
light.9 = 3, 5.00, -0.00, -2.85, fx_f16_navwhih ,
light.10 = 6, 11.00, 0.75, -3.75, fx_shockwave_landing_light_narrow ,
light.11 = 2, -18.40, 0.00, -0.15, fx_f16_ab ,

Use these settings for the F-16D Drag Chute model: (Thanks to Steve "Firebird" Hadlow for keeping me honest). The slight difference is in bold type.

[lights]
//Types: 1=beacon, 2=strobe, 3=navigation, 4=cockpit, 5=landing 6=taxi
light.0 = 2, -19.70, 0.00, 11.45, fx_shockwave_strobe_l ,
light.1 = 3, 10.70, -2.30, -1.50, fx_iris_navred ,
light.2 = 3, 10.70, 2.30, -1.50, fx_iris_navgreen ,
light.3 = 3, -20.40, 0.00, 4.36, fx_f16_navwhih ,
light.4 = 3, -7.00, -15.00, 0.60, fx_iris_navred ,
light.5 = 3, -7.00, 15.00, 0.60, fx_iris_navgreen ,
light.6 = 3, -12.70, -3.20, 0.87, fx_f16_navwhih ,
light.7 = 3, -12.70, 3.20, 0.87, fx_f16_navwhih ,
light.8 = 3, 2.30, -0.00, 2.70, fx_f16_navwhih ,
light.9 = 3, 5.00, -0.00, -2.85, fx_f16_navwhih ,
light.10 = 6, 11.00, 0.75, -3.75, fx_shockwave_landing_light_narrow ,
light.11 = 2, -18.40, 0.00, -0.15, fx_f16_ab ,

**I have elected to use a mix of the Shockwave lights, the default HTAI lights and the Iris light effects for both models.
Last edited by MIKE JG on 17 Nov 2008, 21:54, edited 1 time in total.
-Mike G.

User avatar
MIKE JG
MAIW Developer
MAIW Developer
Posts: 10742
Joined: 12 Aug 2006, 02:25
Version: FS9

Post by MIKE JG »

HTAI C-21 (Learjet 35)


[LIGHTS]
//Types: 1=beacon, 2=strobe, 3=navigation, 4=cockpit, 5=landing 6=taxi
light.0 = 3, -38.60, -20.40, -0.60, fx_Shockwave_navred ,
light.1 = 3, -38.60, 20.40, -0.60, fx_Shockwave_navgre ,
light.2 = 3, -60.00, 0.00, 7.34, fx_Shockwave_navwhi ,
light.3 = 1, -33.03, 0.00, -2.20, fx_Shockwave_beacon_rotating_red , //lower anti-collision light
light.4 = 1, -56.00, 0.00, 8.27, fx_Shockwave_beacon_rotating_red , //upper anti-collision light
light.5 = 6, -35.70, -4.20, -2.30, fx_Shockwave_landing_Light_narrow , //right main gear taxi light
light.6 = 6, -35.70, 4.20, -2.30, fx_Shockwave_landing_Light_narrow , //left main gear taxi light
light.7 = 5, -29.80, -19.50, -0.60, fx_shockwave_landing_light , //left wing tank landing light
light.8 = 5, -29.80, 19.50, -0.60, fx_shockwave_landing_light , //reft wing tank landing light
light.9 = 2, -52.80, -3.90, 0.80, fx_nicksmokeAI_sm_lear ,
light.10 = 2, -52.80, 3.90, 0.80, fx_nicksmokeAI_sm_lear ,

Also the main gear needed a contact point adjustment as well:

[contact_points]
point.0=1, -17.40, 0.00, -4.60, 1181.1, 0, 0.6349, 60.0, 0.4000, 1.5, 0.5100, 4.0, 4.0, 0, 0.0, 0.0
point.1=1, -38.00, -4.20, -4.90, 1574.8, 1, 1.6349, 0.0, 0.6000, 2.5, 0.9100, 5.0, 5.0, 2, 0.0, 0.0
point.2=1, -38.00, 4.20, -4.90, 1574.8, 2, 1.6349, 0.0, 0.6000, 2.5, 0.9100, 5.0, 5.0, 3, 0.0, 0.0

**This setup uses the Shockwave rotating red beacon effect for the anti-collision lights which is the old style beacon that looks like what you see on a fire engine. I've seen Lear 35's with this style as well as a more modern white anti-collision light. You may want to use a different beacon type. I also adjusted the smoke settings and tied them to the strobe lights so that it does not become active until the aircraft takes the runway.
-Mike G.

User avatar
MIKE JG
MAIW Developer
MAIW Developer
Posts: 10742
Joined: 12 Aug 2006, 02:25
Version: FS9

Post by MIKE JG »

Just a word of caution. If you submit light configurations, especially if you have copied them from another website, please check them for accuracy on the model before you post the settings. That includes on the ground as well as in the air. The military versions of some of the models may have a different light setup than their civilian counterpart. Also I'm seeing many errors in the light settings that are being posted on other sites which leads me to believe that people are not checking their work for errors.
-Mike G.

drunkenjim
Second Lieutenant
Second Lieutenant
Posts: 12
Joined: 14 Sep 2006, 21:40
Version: FS9
Contact:

Post by drunkenjim »

MIKE JG wrote:Just a word of caution. If you submit light configurations, especially if you have copied them from another website, please check them for accuracy on the model before you post the settings. That includes on the ground as well as in the air. The military versions of some of the models may have a different light setup than their civilian counterpart. Also I'm seeing many errors in the light settings that are being posted on other sites which leads me to believe that people are not checking their work for errors.
hello mate

some of the ones posted by flyboy were done by me a long time ago, i also did a lot of the ones on the AIG website, what are the errors? i can try and fix any you have found.

one of the problems i have is i modified some of the cfg files of some older ai aircraft to try and make them fly a little better, this will therefore effect the light placings. another which may or may not be an issue is i did some of them in fsx and some in fs9.

laters

jim

User avatar
MIKE JG
MAIW Developer
MAIW Developer
Posts: 10742
Joined: 12 Aug 2006, 02:25
Version: FS9

Post by MIKE JG »

Hello Jim, so far I've only checked the HTAI Lear 35 settings which MAIW uses for the USAF C-21. Is that one of the ones that you originally did?
-Mike G.

drunkenjim
Second Lieutenant
Second Lieutenant
Posts: 12
Joined: 14 Sep 2006, 21:40
Version: FS9
Contact:

Post by drunkenjim »

no mate

Chris' E-3's and the JBAI VC-10's, i think they all work ok, but as usual with no feedback you can never really tell.

laters

jim

User avatar
MIKE JG
MAIW Developer
MAIW Developer
Posts: 10742
Joined: 12 Aug 2006, 02:25
Version: FS9

Post by MIKE JG »

Agreed, lemme check the E-3, I don't have the VC-10 model.

EDIT: The settings look great Jim. I placed a screenshot for the E-3A in that original thread. If you get a chance can you PM me some 800 pixel wide shots of the lights on the VC-10 model and the E-3D model?

The HTAI Lear 35 had all kinds of things wrong with those settings. Just the ones off the top of my head that I remember:
-Wing nav lights were not attached to the wings
-Main gear landing light effect were not attached to the gear legs or lights.
-Those main gear lights were coded as type 5 meaning they would have stayed on and in that same position after the gear was raised.

I could go on but there's no point. As long as people check the entries first, there shouldn't be any problems.
-Mike G.

drunkenjim
Second Lieutenant
Second Lieutenant
Posts: 12
Joined: 14 Sep 2006, 21:40
Version: FS9
Contact:

Post by drunkenjim »

hello mate thanks for looking 8)

i'll see what i can do about some screenies

laters

jim

User avatar
Greg
MAIW Admin
MAIW Admin
Posts: 3839
Joined: 12 Aug 2006, 19:56
Version: P3D
Location: Belgium

Post by Greg »

flyboy wrote:light.3 = 2, -16.20, -26.51, 3.85, fx_Shockwave_strobeh,
Flyboy this effect does not exist, it should be without the "h" at the end. Just adding "shockwave" to the standard effect name is not always enough :wink:

Thanks for all the research guys. Much appreciated.

Greg

User avatar
CelticWarrior
Lieutenant Colonel
Lieutenant Colonel
Posts: 1122
Joined: 15 Aug 2006, 17:16
Version: FSX
Location: Llareggub

Post by CelticWarrior »

Has anyone got a config for the HTAI C-12 and/or RWAI/PAI C-17?
"We attack tomorrow under cover of daylight! It's the last thing they'll be expecting ... a daylight charge across the minefield .."

User avatar
djnocturnal
MAIW Developer
MAIW Developer
Posts: 1376
Joined: 26 Jun 2007, 02:22
Version: P3D
Location: KRDR

Re: Shockwave Lights: Coordinates for MAIW models

Post by djnocturnal »

how about the nbai f-18? :)

User avatar
MIKE JG
MAIW Developer
MAIW Developer
Posts: 10742
Joined: 12 Aug 2006, 02:25
Version: FS9

Re: Shockwave Lights: Coordinates for MAIW models

Post by MIKE JG »

Cary you could just use the most recent configs for those two models from recent MAIW packs (Elmendorf V2). Then just switch out the default or HTAI effects for the SW ones.

This little side project sort of fell off my radar after the "wow" factor of the SW lights wore off.
-Mike G.

User avatar
CelticWarrior
Lieutenant Colonel
Lieutenant Colonel
Posts: 1122
Joined: 15 Aug 2006, 17:16
Version: FSX
Location: Llareggub

Re: Shockwave Lights: Coordinates for MAIW models

Post by CelticWarrior »

Thanks Mike, I think that's what I did.
"We attack tomorrow under cover of daylight! It's the last thing they'll be expecting ... a daylight charge across the minefield .."

User avatar
TheAaron.com
Second Lieutenant
Second Lieutenant
Posts: 85
Joined: 25 Jun 2008, 00:34
Version: FS9
Location: Ipswich, Uk

Re: Shockwave Lights: Coordinates for MAIW models

Post by TheAaron.com »

I think you should keep these up, there looking great on these MAIW aircraft!!!

Thanks for them. :wink:

User avatar
djnocturnal
MAIW Developer
MAIW Developer
Posts: 1376
Joined: 26 Jun 2007, 02:22
Version: P3D
Location: KRDR

Re: Shockwave Lights: Coordinates for MAIW models

Post by djnocturnal »

I wish there were an easier way of adjusting these without having to load up fs9 to see if they are in the correct place. The ones there are coordinates for look great!

User avatar
Firebird
MAIW Admin
MAIW Admin
Posts: 10490
Joined: 11 Aug 2006, 21:04
Version: FS9
Location: EGLL

Re: Shockwave Lights: Coordinates for MAIW models

Post by Firebird »

I use Aircraft Container Manager for that. Some newer aircraft don't show up in their entirety, but most are ok. You can mince around with the settings in the app to get them as right as you would like.

When the development of this proggy stopped they made available a universal key which I have to say was very generous of them. ACM v2.5 was the last version.
Steve
_______________________________________________________
Quid Si Coelum Ruat
_______________________________________________________

User avatar
MIKE JG
MAIW Developer
MAIW Developer
Posts: 10742
Joined: 12 Aug 2006, 02:25
Version: FS9

Re: Shockwave Lights: Coordinates for MAIW models

Post by MIKE JG »

What is the "universal key" that you speak of??? I need it in that case!
-Mike G.

User avatar
Firebird
MAIW Admin
MAIW Admin
Posts: 10490
Joined: 11 Aug 2006, 21:04
Version: FS9
Location: EGLL

Re: Shockwave Lights: Coordinates for MAIW models

Post by Firebird »

The universal key enabled everybody to use its full functionality, now whether you just place this ACMKey.txt in the folder or whether you have to activate this code - i can't remember.
Attachments
ACMKey.zip
(133 Bytes) Downloaded 115 times
Steve
_______________________________________________________
Quid Si Coelum Ruat
_______________________________________________________

Post Reply
